詳細內容

E1 披覆機 chocolate enrobing machine
以自動化機械披覆淋膜在威化、餅乾、蛋捲、膨發食品外觀，可調披覆厚薄設計，讓口味與口感達到客製之最佳均衡。
溶解、調溫、披覆一機完成，輸送帶長短可依產品種類自行調整，風乾距離更可依照需求進行調整，一機多工，靈活度最高。

Automated machinery drape lamination in wafer, biscuits, egg rolls, leavening food appearance, adjustable drape design thickness, taste and texture make the best of customized equalization.

Most flexible enrobing equipment
Dissolution, thermostat, enrobing in one machine, the length of the conveyor belt according to product types adjustable, air-dried can be adjusted in accordance with the distance of more demand,  machine are more functional, most flexible.

主要特色 Functions and Features
●彈性  可因應素材與厚薄等不同客製需求，進行調整。
●安全  採食品級不銹鋼材質，並通過安檢合格。
●品質  全機MIT台灣研發製造生產，優良品質。
●便捷  全自動送料作業，減少人工放取物料流程。
●穩定  恆溫裝置維持巧克力穩定不變質。

flexible:different material with different thickness customization needs can be adjusted.
Security: adopt food-grade stainless steel, and qualified through security.
Quality: The whole machine is MIT ，Taiwan R & D manufacturing quality.
Convenience: automatic feeding operations, reduce manual filling material flow.
Stability: Chocolate thermostat to maintain stability without deterioration.

【適用】
場所：適用各種各式商業空間與生產線使用。
產品：適用威化、餅乾、蛋捲、膨發製品…等多種食品表面披覆巧克力漿料。

【Application】
Place: suitable for various kinds of commercial space and production line.
Product: Applicable wafer, biscuits, egg rolls, extruded cookie and other food products ... surface enrobed chocolate syrup.

●巧克力漿料
選用上好的可可粉，無論純巧克力、白巧克力或者調味巧克力，皆可客製化依照比例調配適合披覆淋膜的漿料。

●優格漿料
優格單吃清爽，而其獨特的濃、純、香，很能提襯食材的鮮度，因此相當適合製成點心食品之披覆漿料使用。

●草莓漿料
草莓是深受廣大女性喜愛的水果，粉紅色澤搭配酸甜滋味，調製成漿料披覆在點心餅乾上，讓聯想起戀愛幸福的滋味。


產品功能 Product production

(1)恆溫攪拌裝置維持醬料穩定不變質。
(2)全機剛材使用304不鏽鋼。
(3)速度/厚薄，均可調整。
(4)全機MIT本廠自行研發製照生產。
(5)可因食材或是厚薄不同客製需求來調整。
(6)全自動化送料作業。

(1)Thermostat stirring device can easy to maintain sauce stability without deterioration.
(2)Machines use 304 stainless steel.
(3)Speed / thickness, can be adjusted.
(4)Our own research and development of the whole machine manufacturing in Taiwan.
(5)The ingredients may be due to different thickness or customization needs to adjust.
(6)Fully automated feeding operations.

精選影片


技術規格表

【規格 Specification】
尺寸 Dimension(cm)	132(H) x 116(W) x 93(D)
電壓 Voltage	220V三相
功率 Power	4800W
重量 Weight	110kg
輸送帶寬度 Conveyor Width	40cm
輸送帶速度 Conveyor Speed	30-800cm/分(M)
醬桶容量 Syrup Tank Capacity	20-80公升(L)
