GP1 脆餅機 Grains Biscuit Machine

高智慧的脆餅生產設備
2014年全新研發機種,採油壓驅動系統設計,為G系列帶來極優越的生產性能。電腦主被動控制系統,提供使用者更靈活的操控,透過人機觸碰介面任意調整製餅厚薄度、餅乾鬆脆度,為穀類製餅設備帶來前所未有的人工智慧。


建議搭配機型




詳細內容



2014年全新研發機種,採油壓驅動系統設計,為G系列帶來極優越的生產性能。電腦主被動控制系統,提供使用者更靈活的操控,透過人機觸碰介面任意調整製餅厚薄度、餅乾鬆脆度,為穀類製餅設備帶來前所未有的人工智慧。

2014 all new developed type which adopt oil pressure transmission system design to bring the G series top excellent production performance. The computer main passive control system provides users more feasible operation. Through user friendly touch surface, you may adjust the thickness and crunchy; it brings the incredible artificial intelligence for grains biscuit making machine.

主要特色 Functions and Features
●酥脆  脆餅餅體口感紮實,保留多種穀物自然風味,酥脆厚薄更能隨心所欲。
●瞬壓  現做,多樣穀類食材,一次瞬間壓製,鎖住原始風味,吸住消費者目光。
●智慧  電腦主被動控制系統,可全自動、手動控制。
●靈活  人機觸碰介面,可任意調整製餅厚薄度及餅乾鬆脆度。
●快速  一次生產6片(多片),快速、連續、高效。
● 多變  可依需求訂製各種造型,如三角形、心形、方形、圓形…都行。

Crispy: The texture of grains biscuit is firmed and keeping the grains nature favor; thickness and crunchy is adjustable.
Press: Live pressing and making grains crackers at site in a moment to lock original favor and to attract consumer’s eyes.
Intelligence: Computer main passive control system, it can be controlled by manual or automatic.
Feasible: User-friendly touch surface can make you adjust the thickness and crunchy as your mind.
Rapid: 6 pieces one time; fast, continuously and fluently.
Variety: The mould can be designed according customer’s designation, such as triangle, heart, square and round..etc..

產品功能 Product production
(1)產量最大之商用機種。
(2)最高產量每秒鐘一片米餅
(3) 採用液壓驅動系統及耐久結構設計,適合長時間或生產線上生產之用。
(4)台灣設計生產。
(5)快速裝卸米桶,另附止料閥。
(6)人機控制介面,操控更精準。
(7) 上下模獨立溫控顯示,可精準控制溫度,確保生產品質。
(8)客戶可自行添加芝麻/黑米/薏仁或其他口味。
(9)提供客製化原料/口味/OEM之服務。

(1)  The highest production in busineess field
(2) The highest production: 1 pcs/sec
(3) Durable and compact construction with Hydraulic-drive system,ideal for long time production line operation.
(4) Design and Made in Taiwan .
(5)Rice tank loading switch for fast changing ingredients, prevent flavor mixed
6)Man-Machine Interface, control more precisely.
(7) Two individual temperature monitor, precise temp. control, ensure product quality.
(8)Provides customization for: Brown rice, Sesame, Black rice Job’s tears and more.
(9)Provide customize ingredients, flavors and OEM service.




技術規格表
【規格Specification
尺寸
Dimension(cm)
146(H) x 51(W) x 46(D)
電壓Voltage 220V單相  1Ø, 220V
功率Power 預熱功率Preheat  2970W
操作功率
​Operation
1760~1980W
產能Capacity 7-10秒seconds / 6片piece(可自行調整Adjustable)
重量Weight 180KG
操作溫度
Operating Temperature
220~260℃
餅乾尺寸
Cookie Size
44.5mm X 6~12mm (厚度 Thickness)
米桶容量
​Rice Tank
6L
